Plex Media Server (1.1.1 )

The API supports responses in both XML and JSON, and clients can request one or the other using the standard Accept HTTP header. The default is XML, so JSON will only be returned if it's explicitly requested (Accept: application/json). New applications should use JSON.

Throughout the docs, it's common for a examples to be given in JSON only since the JSON response would be preferred for new applications.

PMS accept a variety of custom headers that follow the pattern X-Plex-{name}. The full set of headers isn't enumerated here since some may only apply to certain endpoints, but common headers that can be included on all requests include:

Header	Description	Sample
X-Plex-Client-Identifier	An opaque identifier unique to the client	abc123
X-Plex-Token	An authentication token, obtained from plex.tv	XXXXXXXXXXXX
X-Plex-Product	The name of the client product	Plex for Roku
X-Plex-Version	The version of the client application	2.4.1
X-Plex-Platform	The platform of the client	Roku
X-Plex-Platform-Version	The version of the platform	4.3 build 1057
X-Plex-Device	A relatively friendly name for the client device	Roku 3
X-Plex-Model	A potentially less friendly identifier for the device model	4200X
X-Plex-Device-Vendor	The device vendor	Roku
X-Plex-Device-Name	A friendly name for the client	Living Room TV
X-Plex-Marketplace	The marketplace on which the client application is distributed	googlePlay

X-Plex-Client-Identifier is typically required, as is X-Plex-Token for authentication.

There's no standard way to send non-ASCII values as HTTP headers. We attempt to recognize and parse UTF-8 and ISO-8859-1. If you're sending something that may include non-ASCII characters (often X-Plex-Device-Name), use UTF-8 if possible.

These are referred to as headers throughout documentation, but all X-Plex- headers can also be sent as query string arguments.

Most endpoints require token based authentication, and the token is expected to be sent in the X-Plex-Token header. Tokens are obtained from plex.tv. See the Authenticating with Plex section.

Many parts of the API reference things that can be fetched by their key. These keys follow a sort of relative URL resolution pattern. Some examples will help clarify.

• For a request to /library/sections that includes an item with a key of home in the response, that item can be fetched at /library/sections/home.
• For a request to /library/sections/home that includes an item with a key of /library/metadata/deadbeef in the response, that item can be fetched at /library/metadata/deadbeef.

We say this follows a "sort of" relative URL resolution pattern because all requests are treated as though they have a trailing slash.

/library/sections/ + home => /library/sections/home
/library/sections + home => /library/sections/home
/library/sections + /library/sections/home => /library/sections/home

Just like URL resolution, keys may contain absolute URLs as well, especially absolute https://... URLs or custom view://... URLs. In these cases the key resolved by simply using it, the parent is irrelevant.

Also note that the features described in this API can generally be present at a different paths. The /media/providers path defines where all features can be found. Note that a PMS can contain multiple providers which will be enumerated here. For simplicity, these docs use the most common, default paths. But when we say that /library/sections/{id} is part of the API, what we really mean is that a endpoint exists which is composed of the key for the content feature and the key for the library section.

Finally, it's worth noting that many paths can potentially be discovered by walking API responses and fetching keys, but paths that aren't documented here aren't part of the API contract, they just happen to exist for a particular provider. For example, a particular content directory might include a directory with key={baseLibraryPath}/genre. That's not an official part of the API that's guaranteed to exist for every content directory, it's just a key that happened to exist within that content directory.

Many elements throughout the API have a type attribute. These types are meant to give helpful information, such as whether something is a movie library or a TV show library. Some API elements rely on a type number so both are provided below

List of Metadata Types

Type Name	Type Number
movie	1
show	2
season	3
episode	4
trailer	5
person	7
artist	8
album	9
track	10
clip	12
photo	13
photoalbum	14
playlist	15
playlistfolder	16
collection	18

When an element has both type and key attributes, the type describes what will be returned when fetching that key. Some types will return a list of other elements. That list may have a Meta element describing the specific types within the list. Consider the following examples:

[
  {
    "key": "/foo",
    "type": "movie",
    "title": "A Movie"
  },
  {
    "key": "/bar",
    "type": "collection",
    "title": "My Favorite Movies"
  },
  {
    "key": "/baz",
    "type": "show",
    "title": "A Show"
  }
]

In each case, the type describes what will be returned when fetching the key. One exception is the /children key for parents like shows and seasons. It will return a list of children even though the type describes the parent.

Some elements may also include an optional subtype attribute. The subtype is meant to be a refinement of the type, not a completely different type. One test is trying to explain the type in natural language. type="clip" subtype="news" passes the test that "This is a clip, a news clip specifically." Another test is considering the client UI. A client should be functional if it ignores the subtype, and optimized if it respects it. If type="track" subtype="podcast", a client can successfully play the podcast in an audio player based purely on the type, but it may tweak the display or which advanced playback controls are visible based on the subtype.

List of Metadata Subtypes

• podcast
• webshow
• news
• photo

Collection Subtypes

• movie
• show
• artist
• album

Extras Subtypes

• trailer
• deletedScene
• interview
• musicVideo
• behindTheScenes
• sceneOrSample
• liveMusicVideo
• lyricMusicVideo
• concert
• featurette
• short
• other

Source URIs and attributes make it possible to uniquely reference content outside the local server context without requiring a fixed url. This might be desirable when showing related albums from a friend's shared media server, building a universal play queue, or returning aggregated hubs that span multiple providers. Source components are immutable and act as pointers to a single item or directory in the Plex ecosystem.

A source URI from a media server uses the server scheme while a cloud provider uses the provider scheme.

server://{SERVER_ID}/{PROVIDER_ID}/{PATH}
provider://{PROVIDER_ID}/{PATH}

As a single regular expression, that's:

/^(server|provider):\/\/([a-fA-F0-9-]+)?\/?([^/]+)([^\?]+)\??(.*)?/

The server id is the server's machineIdentifier. The provider id is the provider's identifier. The rest of the path represents the path of the content at the provider and may include additional query parameters like X-Plex- headers or media query syntax for sorts and filters.

Some examples may be helpful:

server://546684a3d18ac5c39037360ec9ce900b7af9cc36/com.plexapp.plugins.library/library/metadata/2814936
provider://tv.plex.provider.podcasts/library/sections/audio/all

The source attribute has the same structure as the source URI, but omits the path.

{SOURCE_TYPE}://{SOURCE_ID}/{PROVIDER_ID?}

/^(server|provider):\/\/([a-fA-F0-9-]+)?\/?([^/]+)$/

source="server://546684a3d18ac5c39037360ec9ce900b7af9cc36/com.plexapp.plugins.library"
source="provider://tv.plex.provider.podcasts"

Source attributes can be used as a base and combined with key or other root-relative path components to construct unique source URIs.

Many endpoints that return a list of items support pagination. Additionally some endpoints will force pagination and limit number of elements returned if the client attempts to request all items. To request a specific subset of data, add two headers to specify the starting offset and the number of desired items.

• X-Plex-Container-Start - The desired starting offset
• X-Plex-Container-Size - The desired number of items

Both headers should be sent in order to request paginated content. Note that it's possible to request a size of 0 on supported endpoints in order to learn the total size without actually getting any content.

The response must be checked to see if the response is in fact paginated. The response might not be paginated at all, or it might include a different number of items than what was requested. A paginated response will include the headers:

• X-Plex-Container-Start - The offset of the first returned item
• X-Plex-Container-Total-Size - The total size of the collection (optional but typically present)

The response body will also typically include pagination info. If the response is a MediaContainer, then it will have offset and size attributes representing the start index and the number of items in the current response along with an optional totalSize attribute for the total number of elements in the collection.

HTTP/1.1 200 OK
X-Plex-Container-Start: 2
X-Plex-Container-Total-Size: 5
Content-Type: application/xml

{
  "MediaContainer": {
    "size": 3,
    "totalSize": 5,
    "offset": 2,
    "Metadata" : [
      …
    ]
  }
}

Rather than requesting a page starting at an index, it is also possible in some lists to request a page centered on a specific item in the list.

• X-Plex-Container-Focus-Key - The key of an item to center on
• X-Plex-Container-Size - The desired number of items

The requested size is respected regardless of the position of the focus item in the list. If the item is at the start of the list and 10 items are requested, 9 items in the response will be after the item. If the item is in the middle of the list and 10 items are requested, 4 items will be before the item and 5 items will be after.

Endpoints that support rich media queries also have a limit parameter that interacts with pagination. Sending limit in a query string limits the desired number of items, much like the X-Plex-Container-Size header. There are two major differences:

1. When using limit, the total size of the collection is not returned. The minimum of the limit and the actual total size will be returned as the total size.
2. The request may be more efficient when using limit, since the total size doesn't have to be known.

If the total size of the collection isn't needed, use limit, since the request may be more efficient.

Note that limit and X-Plex-Container-Size aren't mutually exclusive. You can page within the results that are bounded by the limit. If you want a total of 1000 items from a collection of many thousands of items, but you want to page through them 20 at a time, you'd use limit=1000&X-Plex-Container-Size=20&X-Plex-Container-Start=0.

PMS has never used API versioning before the creation of this document. The first published API is considered 1.0 with the API prior to publication considered 0.0. A client species its version via the X-Plex-Pms-Api-Version header on requests. If no header is provided, the version 0.0 is assumed.

API Changes

• 1.0.0 (Supported in PMS >= 1.41.9)

• Added /downloadQueue endpoints.

• Public release of API.

• The includeFields parameter has been renamed to includeOptionalFields. The includeFields parameter now means "include only these fields" where in the past it meant "please add these fields you wouldn't normally include." This was changed to be consistent with the cloud provider API.

• 1.1.0 (Supported in PMS >= 1.42.0)

  • Added ability to filter '/media/providers/metadata' endpoint by metadata types (PM-3702)
  • Changed types in /playlists/{playlistId}/items to array of integers.
  • Document the /photo/:/transcode endpoints
  • Fixed serialization of MetadataType objects for '/media/providers/metadata' calls.

• 1.1.1 (Supported in PMS >= 1.42.2)

  • Added 'metadataAgentProviderGroupId' query param to create and edit library section (PM-3577)
  • Fixed Add library section method type.

Many endpoints allow the data that is included in the response to be tailored to exactly what the client wants. This is possible by either specifying things that should be excluded or the set of things that should be included. PMS's ability to include/exclude elements and fields is currently limited but expanding so this should be used with care.

Attributes can be customized by using a query string arg of either excludeFields or includeFields. This single parameter should be a comma-separated list of attribute names. For example, a request with excludeFields=summary,tagline is asking for the summary and title attributes to be left off any metadata items while the includeFields parameter indicated that only the specified fields should be included.

Child elements can be customized by using a query string arg of either excludeElements or includeElements. This single parameter should be a comma-separated list of element names. For example, a request with excludeElements=Media is asking for the Media elements to be omitted while the includeElements parameter indicated that only the specified elements should be included.

In addition to the above are the parameters includeOptionalFields and includeOptionalElements. These indicate that the fields/elements which are not normally included should be included in this request. One example is includeOptionalElements=musicAnalysis on metadata will include the musicAnalysis parameter which can be large and typically not needed by a client.

Trimming the response to only include what a client will actually use can result in much better performance, especially in large collections. Increasingly these are being used to select which data is fetched from the database. So if a client knows it will only ever use a few parameters from a request, it should specify those with includeFields.

Note that these inclusions/exclusions are treated as requests, not guarantees. Some endpoints will disregard them completely, and others may ignore them for specific items and insist on returning data that the client didn't necessarily ask for.

Media providers are general purpose entities which supply media to Plex clients. Their API describes the Plex Media Server API, via a set of features on the "root" endpoint of the provider. Media provider can be hosted by a media server or in the cloud, linked to a specific Plex account. This section explains media providers generally, and then provides the specific server-hosted APIs around media providers.

Client Guide to Media Providers

The philosophy behind media providers in general is to allow a common API between cloud servers and PMS, since the APIs are nearly identical to a normal PMS. The general guidelines are:

• Consume /media/providers instead of /library/sections

  The new providers endpoint give you a list of all providers exported by a server and their features. Remember that the library itself is considered a (very rich) provider! This change will also require changing the client to not hardwire paths on the server, but rather read them from the feature keys directly (e.g. scrobble and rating endpoints).

• Gate management functionality on the manage feature

  Server libraries allow management (e.g. media deletion). The correct way to gate this functionality is via the manage feature.

• Make sure key construction is correct for things like genre lists

  For example, /library/sections/x/genre returns a relative key for each genre, but there's nothing which says that the key can't be an absolute URL. This is why servers pass back fastKey separately so as to not break clients which don't do key construction correctly. Media providers do not pass back fastKey, but assume clients will be doing correct key construction.

• Don't call /library/sections/X/filters|sorts

  You can get all that information (and more) in a single call by hitting /library/sections/X?includeDetails=1. Media providers include the extra information by default.

• Respect the Type keys in /library/sections/x

  The top-level type pivots have their own keys, which should be used over the old "just append /all to the path and add the type" approach. Not only is this more flexible, it also allows for "virtual" pivots, like music videos inside a music library.

• Look for the skipChildren/skipParent attributes for shows

  Because of things like Podcasts, single-season shows can now be made to skip seasons. This is indicated by a skipChildren attribute on the show, or a skipParent attribute on an episode. If this is set on a show, the client should use /grandchildren instead of /children in the show's key.

Features

The list of supported features, along with the API endpoints each feature represents is shown in the following list. Note that each feature can define a custom endpoint URL, so it doesn't have to match the server API exactly.

• search: This feature implies that it supports search via the provided key.

• metadata: This feature implies that it supports metadata endpoint. For example, if the key were /library/metadata then the endpoints /library/metadata/X, /library/metadata/X/children and /library/metadata/X/grandchildren would be supported. This endpoint family allows browsing a hierarchical tree of media (e.g. show to episodes, or artist to tracks).

• content: This feature implies that the provider exposes a content catalog, in the form of libraries to browse (grid of content), or discover (via hubs). Each entry in the content feature can contain:

  • hubKey: This implies it supports a discovery endpoint with hubs.
  • key: This implies it supports a content catalog.
  • icon: Optional, specifies the icon used for a content directory.

  Each content feature can contain one or both of these keys, depending on the structure. More details on the various combinations are provided below.

• match: The match feature is used to match a piece of media to the provider's content catalog via a set of hints. As a specific example, you might pass in a title hint of "Attack of the 50 Foot Woman" and a year hint of 1958 for the movie type. The provider would then use all the hints to attempt to match to entries in its catalog.

• manage: The manage feature implies a whole host of endpoints around changing data inside a library (e.g. editing fields, customizing artwork, etc.). This feature is generally only available on an actual server and generally only to the admin.

• timeline: The timeline feature implies that the provider wants to receive timeline (playback notifications) requests from a client at the endpoint defined by key. The feature may additionally specify the scrobbleKey and unscrobbleKey attributes, which represent the endpoints which allow marking a piece of media played or unplayed.

• rate: This feature implies the provider supports the endpoint which allows rating content.

• playqueue: This feature implies the provider supports the play queue family of endpoints. The flavor attribute further specifies the subset; the only supported flavor is currently full.

• playlist: This feature implies the provider supports the playlist family of endpoints. If readonly is set, that means that the provider only allows listing and playing playlists (via play queue API), not actually creating or editing them.

• subscribe: This provider allows media subscriptions to be created. If the flavor is record then media can be recorded from this library (such as DVR). If the flavor is download then the user is allowed to download from this library.

• promoted: This feature allows the provider to supply an endpoint that will return a collection of "promoted" hubs that many clients show on a user's home screen.

• continuewatching: This feature allows the provider to supply an endpoint that will return a hub for merging into a global Continue Watching hub.

• collection: This feature implies the provider supports the collection family of endpoints.

• actions

  • removeFromContinueWatching - Action to remove an item from continue watching

• imagetranscoder - This feature implies the provider supports the image transcoder endpoints used to scale images for clients where memory and processor is at a premium

• queryParser - This feature implies the provider supports the media queries language below

• grid - This feature implies the provider supports displaying metadata in a grid over time (such as live TV)

Home discovery and browsable libraries

Shown in the example in /media/providers, in this media provider the first content directory is an item with only hubKey, meaning it only providers discovery hubs. This is the set of hubs covering the whole library which contains continue watching, recently added, recommendations, etc. It's essentially "landing page" for the provider.

The subsequent directories also have a browse key, which means they provide a list view of the content with options for filtering and sorting. EPG providers may have only the key and no hubKey.

Minimal provider

There's no requirement to provide the content feature, given that there are two other ways to access content within a provider: search and match. The former can contribute to global search, whereas the latter is used for things like the DVR engine; once media subscriptions are set up, they look for matching content using the match feature, and examined using the metadata feature.

Deeper Hierarchies

If you examine an app like Spotify, you'll see many of the concepts here apply to their content hierarchy. Their content screens are either grids or hubs. But one notable difference is that the content hierarchy runs a bit deeper than the examples we've examined thus far. For example, one of the top-level selections is "Genres & Moods". Diving into one of the genres leads to a discovery area with different hubs for popular playlists, artists, and albums from the genre. Selecting a mood leads to a grid with popular playlists for the mood. In order to support this sort of hierarchy, we need an extension to the regular library, which is a content directory. This allows us to nest content, without losing any of the power and features—for example, the grid with popular playlists could list filters and sorts specific for that grid. This is power you simply don't have with the old channel architecture.

Extensions to regular libraries

This section examines extensions to plain libraries which content providers can use, and which clients need to be aware of.

• Nested content directories: In regular libraries, there are fixed types of directories (e.g. shows, or music albums). In content providers, we want to have the ability to display other types of things (e.g. stations, or moods, or genres) as first-class things in a grid or discovery layout. Here's an example of what a nested content directory looks like. Given the type of content, the client knows that this directory should be treated like a content directory feature entry.

  {
    "Directory":[
      {
        "key":"foo",
        "hubKey":"foo2",
        "type":"content",
        "aspectRatio":"1:1",
        "title":"Genres and Moods"
      }
    ]
  }


• Aspect ratio hint: Because the entities listed in content directories can be arbitrary, it's important to tell the client some information about how they should be displayed. The thumb attribute contains no information about aspect ratio, so clients make assumptions based upon known types (e.g. movies are 2:3, episode thumbs are 16:9, etc.). This attributes allows the provider to specify exactly the aspect ratio of the thing being displayed.

Media queries are a querystring-based filtering language used to select subsets of media. The language is rich, and can express complex expressions for media selection, as well as sorting and grouping.

Fields

Queries reference fields, which can be of a few types:

• integer: numbers
• boolean: true/false
• tag: integers representing tag IDs.
• string: strings
• date: epoch seconds
• language: string in ISO639-2b format.

These fields are detailed in Field elements in the section description endpoint (e.g. /library/sections/X?includeDetails=1).

Operators

Given that media queries are expressible using querystrings, the operator syntax might look a bit quirky, because a) they have to include the = character, and b) characters to the left of the equal sign usually have to be URI encoded.

Operators are defined per type:

• integer: = (equals), != (not equals), >>= (greater than), <<= (less than), <= (less than or equals), >= (greater than or equals)
• boolean: =0 (false) and =1 (true)
• tag: = (is) and != (is not)
• string: = (contains), != (does not contain), == (equals), !== (does not equal), <= (begins with), >= (ends with)
• date: = (equals), != (not equals), >>= (after), <<= (before)
• language: = (equals), != (not equals)

Relative Values and Units

For some types, values can be specified as relative. For dates, epoch seconds can be specified as relative to “now” as follows: +N (in N seconds from now and -N (N seconds ago).

In addition, the following unit suffixes can be used on date values:

• m: minutes
• h: hours
• d: days
• w: weeks
• mon: months
• y: years

For example, >>=-3y means “within the last 3 years”.

Field Scoping

Some media is organized hierarchically (e.g. shows), and in those cases, many fields are common to different elements in the hierarchy (e.g. show title vs episode title). The following rules are used to resolve field references.

• A type parameter must be included to specify the result type.
• Any non-qualified field is defaulted to refer to the result type.
• In order to refer to other levels of the hierarchy, use the scoping operator, e.g. show.title or episode.year. A query may be comprised of multiple fields from different levels of the hierarchy.
• the sourceType parameter may be used to change the default level to which fields refer. For example, type=4&sourceType=2&title==24 means “all episodes where the show title is 24”.

Sorting

The sort parameter is used to indicate an ordering on results. Typically, the sort value is a field (including optional scoping). The : character is used to indicate additional features of the sort, and the , character is used to include multiple fields to the sort.

For example, sort=title,index means “sort first by title ascending, then by index”. Sort features are:

• desc: indicates a descending sort.
• nullsLast: indicates that null values are sorted last.

Sort features may be mixed and matched, e.g. sort=title,index:desc.

Grouping

The group parameter is used to group results by a field, similar to the SQL feature group by. For example, when listing popular tracks, we use the query type=10&sort=ratingCount:desc&group=title, because we don't want multiple tracks with the same name (e.g. same track on different albums) showing up.

Limits

The limit parameter is used to limit the number of results returned. Because it's implemented on top of the SQL limit operator, it currently only operates at the level of the type returned. In other words, type=10&limit=100 will return at most 100 tracks, but you can't select tracks from a limit of 10 albums.

Boolean Operators

Given the nature of querystrings, it makes a lot of sense to interpret the & character as a boolean AND operator. For example rating=10&index=5 means “rating is 10 AND index is 5”.

We leverage the , operator to signify the boolean OR operator. SO rating=1,2,3 means “rating is 1 OR 2 OR 3. Given standard precedence rules, rating=1,2,3&index=5 is parsed as (rating = 1 or rating = 2 or rating = 3) and index = 5).

Complex Expressions

There's only so many expressions you can form using vanilla querystring-to-boolean mapping (essentially, “ANDs of ORs”). In order to fully represent complex boolean expressions, there are a few synthetic additions:

• push=1 and pop=1: These are the equivalent of opening and closing parenthesis.
• or=1: These is an explicit OR operator.

As an example: push=1&index=1&or=1&rating=2&pop=1&duration=10 parses into (index = 1 OR rating = 2) AND duration = 10. This could not be expressed by the simplified syntax above.

Happy query building!

The universal transcode endpoint supports the following header or query string parameter: X-Plex-Client-Profile-Extra.

The value of this parameter is url-encoded. When url-decoded, it consists of a string expressed in the following (poor man's) BNF grammar:

<ProfileExtension> ::= <Directive> "+" <Directive>*
<Directive> :: = <Verb> <Arguments>
<Verb> ::= "add-direct-play-profile" | "add-limitation" | "add-transcode-target-codec" | "append-transcode-target-codec" | "add-transcode-target" | "add-settings"
<Arguments> ::= "(" (<Name> "=" <Value>) "&")*
<Name> ::= <Text>
<Value> ::= <Text>

add-direct-play-profile

This directive augments the set of Direct Play profiles in the client profile. The following parameters are required:

• type = "videoProfile" | "musicProfile" | "photoProfile" | "subtitleProfile"
• container = * or a comma-separated list of containers
• videoCodec = * or a comma-separated list of video codecs
• audioCodec = * or a comma-separated list of audio codecs
• subtitleCodec = * or a comma-separated list of subtitle formats

* means to use all existing matching values in the profile. At least one of the videoCodec, audioCodec and subtitleCodec parameters must not be *.

add-direct-play-profile example

To add ac3 as a video audio codec for mp4 and mov containers:

add-direct-play-profile(type=videoProfile&container=mp4,mov&videoCodec=*&audioCodec=ac3&subtitleCodec=*)

add-limitation

This directive adds a scoped limitation to the profile. The following parameters are required:

• scope = "videoContainer" | "musicContainer" | "photoContainer" | "videoCodec" | "videoAudioCodec" | "musicCodec" | "subtitleCodec" | "transcodeTarget"
• scopeName = the name of the relevant container or codec
• type = "match" | "notMatch" | "upperBound" | "lowerBound"
• name = the name of the limitation

The following parameters are optional:

• isRequired = true|false (default is false)
• allStreams = true|false (default is false)
• replace = true|false (default is false)

If the replace parameter is true, the limitation will replace any similarly scoped limitations (i.e. identical scope and scopeName. If false, the new limitation will simply add itself to the list of limitations.

Exactly one of the following three parameters is required:

• value = the value of the limitation
• substring = the substring of the limitation
• regex = the regex of the limitation

The transcodeTarget scope exists to attach a limitation to a transcode target. This allows clients to tell the MDE to select a specific transcode target for a context/protocol pair, based on specific information about the media itself. When multiple transcode targets match, the first one in the profile will be selected.

add-limitation examples

To add a limitation on ac3 audio tracks in video media specifying a maximum of 6 channels:

add-limitation(scope=videoAudioCodec&scopeName=ac3&type=upperBound&name=audio.channels&value=6)

To add a limitation on ac3 audio tracks in video media specifying a maximum bitrate:

add-limitation(scope=videoAudioCodec&scopeName=ac3&type=upperBound&name=audio.bitrate&value=160)

To add a limitation on h264 video specifying a maximum level:

add-limitation(scope=videoCodec&scopeName=h264&type=upperBound&name=video.level&value=40&isRequired=true)

To add a limitation to a transcode target:

add-limitation(scope=transcodeTarget&scopeName=MyTranscodeProfile&type=upperBound&name=audio.channels&value=2)

add-transcode-target-codec

This directive adds additional codecs to the beginning of the audioCodec and/or subtitleCodec lists for the specified transcode target. The following parameters are required:

• type = "videoProfile" | "musicProfile" | "photoProfile" | "subtitleProfile"

Either id or context and protocol are required:

• id = a transcode target identifier
• context = a transcode context ("streaming" | "static")
• protocol = a protocol ("hls" | "http" | "slss" ... )

At least one of the following parameters are also required:

• videoCodec = a comma-separated list of videoCodecs, which are added to the set of video codecs on the target.
• audioCodec = a comma-separated list of audioCodecs, which are added to the set of audio codecs on the target.
• subtitleCodec = a comma-separated list of audioCodecs, which are added to the set of subtitle codecs on the target.

add-transcode-target-codec example

To add ac3 as an additional transcode target option to a HTTP Live Streaming target:

add-transcode-target-codec(type=videoProfile&context=streaming&protocol=hls&audioCodec=ac3)

append-transcode-target-codec

This directive appends additional codecs to the end of the audioCodec and/or subtitleCodec lists for the specified transcode target. The parameters are the same as for add-transcode-target-codec.

append-transcode-target-codec(type=videoProfile&context=streaming&protocol=hls&audioCodec=dca)

add-transcode-target

This directive adds a new transcode target. If a transcode target matching the type/context/profile already exists in the profile, then this directive is ignored. The following parameters are required:

• type = "videoProfile" | "musicProfile" | "photoProfile" | "subtitleProfile"
• context = a transcode context ("streaming" | "static")
• protocol = a protocol ("hls" | "http" | "slss" ... )
• container = a container

The following parameters are optional:

• id = a transcode target identifier
• replace = true|false (default is false)

If the replace parameter is true, the transcode target will replace any similarly scoped transcode target (i.e. identical type, context and protocol. If false, the augmentation will fail if there is an existing transcode target.

The following parameters are required, depending on the type:

• videoCodec = a video codec (required for video) or a comma-separated list of video codecs
• audioCodec = an audio codec (required for music and video) or a comma-separated list of audio codecs
• subtitleCodec = an subtitle codec (required for subtitles and optional for video) or a comma-separated list of subtitle codecs

add-transcode-target examples

add-transcode-target(type=videoProfile&context=streaming&protocol=http&container=mkv&videoCodec=h264&audioCodec=aac,ac3&subtitleCodec=srt)

add-transcode-target(type=musicProfile&context=streaming&protocol=http&container=flac&audioCodec=flac)

add-transcode-target(type=subtitleProfile&context=all&protocol=http&container=webvtt&subtitleCodec=webvtt)

add-settings

This directive overrides global settings for the profile. The parameters are name/value pairs matching existing client profile settings.

add-settings(DirectPlayStreamSelection=false&RandomAccessDataModel=limited)

Plex supports two authentication methods:

JWT Authentication (Recommended)

Plex now supports JSON Web Token (JWT) authentication that provides better security, shorter token lifespans, and improved protection against potential security breaches.

Why JWT Authentication?

The new JWT system addresses security concerns by:

• Short-lived tokens: Tokens expire after 7 days
• Public-key cryptography: Uses modern cryptographic standards (ED25519) for enhanced security
• Better clock synchronization: Built-in timestamp validation helps devices stay in sync

How JWT Authentication Works

The new system uses a public-key authentication model where each device uploads a public key (JWK) and then requests short-lived JWT tokens. Here's the flow:

1. Device Key Registration First, your device needs to register its public key with Plex.tv:

POST https://clients.plex.tv/api/v2/auth/jwk
Headers:
  X-Plex-Client-Identifier: your-device-identifier
  X-Plex-Token: your-existing-token

Body:
{
  "jwk": {
    "kty": "OKP",
    "crv": "Ed25519",
    "x": "your-public-key-data",
    "use": "sig",
    "alg": "EdDSA"
  }
}

2. Token Refresh Process Once registered, your device can refresh its token every 7 days using this three-step process:

Step 1: Get a Nonce

GET https://clients.plex.tv/api/v2/auth/nonce
Headers:
  X-Plex-Client-Identifier: your-device-identifier

This returns a unique nonce valid for 5 minutes:

{
  "nonce": "7c415b56-8f48-488a-98ab-847ef4460442"
}

Step 2: Create a Device JWT Your device creates a JWT containing:

• The nonce from step 1
• Required scope permissions (see Scope Details below)
• Audience set to plex.tv
• Issuer set to your client_identifier
• Signed with your device's private key

Scope Details: The scope field in your device JWT should contain comma-separated values for the user data you need included in the JWT:

• username - Access to the user's username
• email - Access to the user's email address
• friendly_name - Access to the user's friendly name
• restricted - Access to the user's restricted status
• anonymous - Access to the user's anonymous status
• joinedAt - Access to the user's account creation timestamp

Example Device JWT Payload:

{
  "nonce": "7c415b56-8f48-488a-98ab-847ef4460442",
  "scope": "username,email,friendly_name",
  "aud": "plex.tv",
  "iss": "your-client-identifier",
  "iat": 1705785603,
  "exp": 1705789203
}

Step 3: Exchange for Plex Token

POST https://clients.plex.tv/api/v2/auth/token
Headers:
  X-Plex-Client-Identifier: your-device-identifier

Body:
{
  "jwt": "your-device-signed-jwt"
}

This returns a new Plex.tv JWT valid for 7 days:

{
  "auth_token": "eyJraWQiOiJYeVRRN21seXFtVmhJcEo0U1pDZGltdXo3ZjdEYXU1Ym9MLXU2MG5JeEdJIiwidHlwIjoiSldUIiwiYWxnIjoiRWREU0EifQ..."
}

Using Your JWT Token Once you have a JWT token, use it exactly like the old tokens in the X-Plex-Token header:

GET https://clients.plex.tv/api/v2/library/sections
Headers:
  X-Plex-Token: your-jwt-token

JWT Authentication Benefits

Security Features:

• Token Rotation: Automatic expiration every 7 days
• Individual Revocation: Each device can be individually disabled
• Cryptographic Verification: Uses industry-standard ED25519 signatures
• Nonce Protection: Prevents replay attacks

Developer Experience:

• Familiar Interface: Same X-Plex-Token header usage
• Automatic Clock Sync: Built-in timestamp validation
• Clear Error Codes: Specific error responses for different failure modes
• Rate Limiting: Built-in protection against abuse

Error Handling

The JWT system provides clear error responses with specific HTTP status codes:

• 498 Token Expired: Your JWT has expired and needs refresh
• 422 Signature Verification Failed: Invalid device signature or JWT structure
• 422 Thumbprint Already Taken: JWK already registered by another device
• 400 Bad Request: Invalid request format or missing required fields
• 429 Too Many Requests: Rate limit exceeded (nonce requests are rate-limited)

Migration Guide

For New Applications:

1. Generate an ED25519 key pair for your device
2. Register your public key using POST https://clients.plex.tv/api/v2/auth/jwk
3. Implement the token refresh flow
4. Use the returned JWT in your X-Plex-Token header

For Existing Applications:

1. Continue using your current token for now
2. Implement JWT authentication alongside existing auth
3. Test the new system thoroughly
4. Switch over when ready

Traditional Token Authentication (Legacy)

You're developing an app that needs access to a user's Plex account. To do this, you'll need to get access to the user's Access Token. This document details how to check whether an Access Token is valid, and how to obtain a new one.

High-level Steps

1. Choose a unique app name, like "My Cool App"
2. Check storage for your app's Client Identifier; generate and store one if none is present.
3. Check storage for the user's Access Token; if present, verify its validity and carry on.
4. If an Access Token is missing or invalid, generate a PIN, and store its id.
5. Construct an Auth App url and send the user's browser there to authenticate.
6. After authentication, check the PIN's id to obtain and store the user's Access Token.

Detailed Steps

1. Choose a unique app name

   The app name you choose will be visible in the user's Authorized Devices view. The name you choose should be different from any existing Plex products.

2. Generate a Client Identifier

   The Client Identifier identifies the specific instance of your app. A random string or UUID is sufficient here. There are no hard requirements for Client Identifier length or format, but once one is generated the client should store and re-use this identifier for subsequent requests.

3. Verify stored Access Token validity

   You can check whether a user's stored Access Token is valid by requesting user info from the plex.tv API and examining the HTTP status code of the response.

   $ curl -X GET https://plex.tv/api/v2/user \
     -H 'Accept: application/json' \
     -H 'X-Plex-Product: My Cool App' \
     -H 'X-Plex-Client-Identifier: <clientIdentifier>' \
     -H 'X-Plex-Token: <userToken>'


   HTTP Status Code
   200	Access Token is valid
   401	Access Token is invalid

   If an Access Token is invalid, it should be discarded, and new one should be obtained through the authentication process.

   If plex.tv cannot be reached, or if you receive any other status code it indicates an error state, but does not indicate an invalid Access Token.

4. Generate a PIN

   To sign a user in, the app must create a time-limited PIN. The user is then led through a process to "claim" the PIN, associating it with their account and granting the app access to the user's plex.tv account.

   $ curl -X POST https://plex.tv/api/v2/pins?strong=true \
     -H 'Accept: application/json' \
     -H 'X-Plex-Product: My Cool App' \
     -H 'X-Plex-Client-Identifier: <clientIdentifier>'


   Note: the strong=true header provides a longer length pin which will have a longer lifetime. This is useful in cases where the user is not expected to type in the pin themselves. If not specified, a shorter pin is created but will have a much shorter lifetime.

   The response will be a JSON payload; the two important properties are id and code. Store the id locally, and use the code to construct the Auth App url.

   {
     "id": 564964751,
     "code": "8lzjqnq8lye02n52jq3fqxf8e",
     …
   }


5. Checking the PIN

   There are two primary ways apps interact with the Auth App and the PIN-claiming process; Forwarding and Polling.

   Forwarding is used by web-based apps. A user visits your app in their web browser, leaves your app to authenticate with Plex, and returns to your app via a forwardUrl your app provides.

   Polling is used by native apps running outside of a web browser. A user indicates their intention to sign-in from within your app, and your app opens a web browser pointing to the Auth App where the user completes sign-in. Your app will periodically poll on the generated PIN until it is claimed, or it expires.

6. Construct the Auth App url

   The user will authenticate with the plex.tv Auth App through their web browser.

   If you're using the Forwarding flow, the user will be returned to your app after authenticating where you'll be able to check the created PIN to determine the user's Access Token. The forwardUrl to which the user will be returned can carry the PIN id which needs to be checked on their return to the app.

   Auth App urls are encoded as parameters to the url fragment. Practically, this means that your Auth App url will be prefixed with https://app.plex.tv/auth#?; the #? at the end indicates the beginning of the url fragment, and that the content of the fragment afterwards is encoded as url parameter key-values pairs.

   Append these parameters to construct the final URL.

   Parameter
   clientID	Your client identifier
   code	The code from the generated PIN
   forwardUrl	The url to which the user will be returned after authenticating.
   context%5Bdevice%5D%5Bproduct%5D	The name of your App; ex "My Cool App"

   Example

   https://app.plex.tv/auth#?clientID=<clientIdentifier>&code=<pinCode>&context%5Bdevice%5D%5Bproduct%5D=My%20Cool%20Plex%20App&forwardUrl=https%3A%2F%2Fmy-cool-plex-app.com


   You can use the qs module to encode all necessary parameters, including the nested context parameter.

   const authAppUrl =
     'https://app.plex.tv/auth#?' +
     require('qs').stringify({
       clientID: '<clientIdentifier>',
       code: '<pinCode>',
       forwardUrl: 'https://my-cool-plex-app.com',
       context: {
         device: {
           product: 'My Cool App',
         },
       },
     });


7. Send user's browser to constructed Auth App url

   Once the Auth App URL has been constructed, send the user's browser there to authenticate.

8. Check PIN

   If you're using the Polling flow, your app should periodically (once per second) check the PIN id to determine when the user has signed-in.

   If you're using the Forwarding flow, check the stored PIN id from the PIN creation step. If the PIN has been claimed, the authToken field in the response will contain the user's Access Token you need to make API calls on behalf of the user. If authentication failed, the authToken field will remain null.

   $ curl -X GET 'https://plex.tv/api/v2/pins/<pinID>' \
     -H 'Accept: application/json' \
     -H 'X-Plex-Client-Identifier: <clientIdentifier>'


Talking to PMS

Once you have a token to talk to plex.tv, you will need to obtain a different set of tokens used to talk to PMS instances.

$ curl https://clients.plex.tv/api/v2/resources?includeHttps=1&includeRelay=1&includeIPv6=1 \
  -H 'Accept: application/json' \
  -H 'X-Plex-Product: My Cool App' \
  -H 'X-Plex-Client-Identifier: <clientIdentifier>' \
  -H 'X-Plex-Token: <userToken>'

The response will be a JSON document which will contain available PMS instances, the accessToken used in communication with this PMS, and the list of connection URLs where the PMS may be contacted. Connections labeled as local should be preferred over those that are not, and relay should only be used as a last resort as bandwidth on relay connections is limited.

General endpoints for basic PMS operation not specific to any media provider

Library endpoints which are outside of the Media Provider API. Typically this is manipulation of the library (adding/removing sections, modifying preferences, etc).
